- At least 25% greater WLL than traditional Grade 8 products.
- Testing according to DIN PAS 1061 and ASTM A952/A 952M.
- Proof load tested at 2.5 times the WLL with certification for each batch manufactured. Fatigue rated to 20,000 cycles at 1.5 times the WLL.
- Designed for the assembly of chain slings where wide throat openings are necessary
When fitting G10 components are added to G8 chain, the sling is rated at G8 WLL.
- Material: Quenched and Tempered Alloy Steel.
- Marking: According to standard, Size, grade, manufacturer ID, traceability.
- Temperature range: -40ºC up to +200°C (without reduction in WLL).
-
Standard:
EN 1677-1
Australian Standard: AS 3776 - Warning: Before using the hook, check whether hooks without safety latches are allowed to be used for the particular application.
- Safety factor: 4:1
- Grade: 10
